Can paper wrapping machine BQL-CLD30

The BQL-CLD30 wrapping and packaging machine consists of a can feeding section, a can splitting section, a suction box feeding section, a folding and forming section, a spray adhesive bonding section, a pneumatic section, and an electronic control section,

According to customer packaging requirements,

Accurately group the single feed from the canning machine; At the same time, the cardboard suction mechanism synchronously delivers the packaging cardboard boxes to the bottom of each group of products,

The final packaging of the product is completed by coordinating the work of the forming folding mechanism and the spray adhesive bonding device; The synchronization of each part is achieved by several servo motors and mechanical adjustment synchronization,

To ensure accurate, qualified, and aesthetically pleasing packaging for each group of products.

BQL-CLD30 paper wrapping machine is a specialized product packaging for cans. It is an automated packing machine for cans, with a wide range of applications and strong practicality.

This machine has a mesh belt conveyor that arranges the products neatly, dividing them into six rows, five rows, or four rows (depending on the packaging method),

In addition, the paper is also stacked on one side. Using the principle of a robotic arm, the paper is pulled down and then pushed by a roller conveyor. When the paper and product reach the positioning point, the machine's pushing mechanism swings left and right to make the product lightly fall onto the paper,

There is a set of cylinders and suction cups under the paper, and the paper and product are pulled down to form,

After forming, use a chain drive to move forward and repeat the forward movement. After the box is formed, spray glue and adhesive action will be performed for each forward movement,

And push it forward onto the conveyor, then perform the stacking pallet action.A
